48Vdc 12kw Hybrid Inverter Split Phase 120V 240V 110V 220V
Original price was: $1,550.00.$1,520.00Current price is: $1,520.00.
Output Power:12000W
Input Voltage:48VDC
Output Voltage:110V/220VAC, 120V/240VAC
Output Frequency:50hz/60hz
Controller type: MPPT
Size:765*320*250mm
Weight:71kg
48Vdc 12kw Hybrid Inverter Split Phase 120V 240V 110V 220V
Specification
Rated power
|
12000W
|
Input Voltage
|
180-260VAC(AC:220)
|
Frequency
|
50/60Hz±3
|
Output Voltage
|
110V/220V, 120V/240V AC
|
Output waveform
|
Pure sine wave
|
Efficiency
|
>95%
|
Type of battery
|
Optional
|
Battery rated voltage
|
48V dc
|
AC charging current
|
0-35A
|
Protection
|
Overload: Rated power over 110%, shut down automatically, short circuit: Automatic Shutdown
battery high and low voltage
AC input high and low voltage protection
|
Solar Charger Controller
|
MPPT solar controller
|
MPPT Current
|
50A,60A,100A(optional)
|
Communication port
|
RS232/SNMP(Optional)
|
Product Description
Feature:
~ Pure sine wave output
~ With MPPT solar charge controller 30A-100A(Optional)
~ It has perfect protection functions such as overload, high voltage, low voltage, short circuit, etc
~ With UPS automatic switching function, grid power charging function, AVR voltage stabilization function ~ DSP Intelligent Chip Control, Excellent Performance
~ Strong inverting capability, one-time soft start, triple output peak power, with all inductive loads
~ Full personalized LCD display, it can display various data information of inverter, solar charge controller ~ Grid power priority, energy saving mode and solar energy priority can be set free to meet different occasions
~ Battery type, charging voltage grid power charging current (0-35A) can be set free to meet the charging management of different types of batteries
