All-in-one Off Grid Inverter Solar Inverter 5kw Off-grid Inverter Charger 3kva 30A 60A 220Vac
5kw Off-grid Inverter Charger Display real-time power generation, support lead-acid lithium battery, photovoltaic priority mains complement
[vc_row][vc_column][vc_column_text]MPPT Offgrid Solar Inverter 500W 800W 1000W 2000W 3000W 4000W 5000W 6000W All In One Inverter Shenzhen Solar Inverter MPPT
Product Features:
Power frequency pure sine wave output, low loss and high efficiency.
City power priority/ECO/PV priority can be set, application is flexible.
PV STRAIGHT IN Up to 150 VDC/Max:3400W.
UPS/Solar inverter;
BUILT-IN PWM/MPPT solar controller( Optional );
AVR, 85-135Vac/165 -275Vac,The generator can be connected to work ;
|
Rated Power(W)
|
500W
|
500W
|
800W
|
800W
|
1000W
|
1000W
|
|
|
Peak power (W) 15ms
|
1000W
|
1000W
|
2400W
|
2400W
|
3000W
|
3000W
|
|
|
Start motor (HP )
|
100-350W
|
||||||
|
Nominal battery voltage ( Vdc )
|
12V/24Vdc or li-battery
|
||||||
|
Host size ( L*W*Hmm )
|
348*148*225mm
|
||||||
|
Host size ( L*W*Hmm )
|
395* 190*265mm
|
||||||
|
Net weight (Kg )
|
5.5Kg
|
6.5Kg
|
7.5Kg
|
||||
|
Net weight (Kg )
|
6Kg
|
7Kg
|
8Kg
|
||||
|
Rated Power(W)
|
1500W
|
2000W
|
3000W
|
4000W
|
5000W
|
6000W
|
|
|
Peak power (W) 15ms
|
4500W
|
6000W
|
9000W
|
12000W
|
15000W
|
18000W
|
|
|
Start motor (HP )
|
1HP
|
1.5HP
|
2HP
|
3HP
|
4HP
|
4HP
|
|
|
Nominal battery voltage ( Vdc )
|
12V/24V/48Vdc or li-battery
|
24V/48V/96Vdc or li-battery
|
|||||
|
Host size ( L*W*Hmm )
|
465*355*1 70mm
|
530*355* 170mm
|
|||||
|
Packing size ( L*W*Hmm )
|
535*395* 240mm
|
605*395*240mm
|
|||||
|
Net weight ( Kg)
|
17Kg
|
18.5Kg
|
22Kg
|
25Kg
|
30Kg
|
33Kg
|
|
|
Gross weight ( Kg)
|
17.5Kg
|
19Kg
|
22.5Kg
|
26Kg
|
31Kg
|
34Kg
|
|
|
AC Input |
Phase Sequence
|
L+N+PE
|
|||||
|
Voltage Frequency
|
85VAC-135VAC/165VAC 275VAC 38-65HZ Automatic tracking
|
||||||
|
Low voltage range
|
85VAC/165VAC+5%
|
||||||
|
Low voltage range
|
95VAC/175VAC+5%
|
||||||
|
High voltage range
|
135VAC/275VAC +5%
|
||||||
|
High voltage range
|
125VAC/265VAC+5%
|
||||||
|
AC Output
|
Phase Sequence
|
L+N+PE
|
|||||
|
AC Voltage
|
110V/1 20V/220/230V/240Vac土5%( Inverter mode )
|
||||||
|
AC Frequency
|
50Hz/60Hz +1% ( Inverter mode )
|
||||||
|
Output Waveform
|
Pure sine wave
|
||||||
|
Inverter no-load loss
|
≤20W
|
||||||
|
Conversion time
|
≤4ms
|
||||||
|
Harmonic distortion
|
THD3% ( Resistive load )
|
||||||
|
Conversion efficiency
|
>90% ( 88%Resistive load )
|
||||||
|
Built-in Solar |
Charging Type
|
MPPT or PWM
|
|||||
|
Controller Current
|
20A/30A/40A/50A/60A
|
||||||
|
Input voltage |
MPPT/12V:18-150V(36V);24V:36-150V(60-72V);
48V : 60-150V(90-120V); 96V : 120-180V; ( Optimum value )
|
||||||
|
PWM/12V system:18V; 24V system:30 -50V(36V);
48V system : 60 100V(72V); 96V system: 120- 170V(150V);
|
|||||||
|
Charging efficiency
|
MPPT> 99% ;PWM> 80%
|
||||||
|
Max solar power
|
12V system : 280W/420W/570W/700W/900W ;
24V system : 550W/840W/1130W/1400W/1700W;
48V system : 1100W/1650W/2270W/2800W/3400W ;
96V system : 50A-5600W/60A- 6800W ;
|
||||||
|
Working |
Grid First
|
The State Grid Power supply is preferred,and the power grid fault is automatically switched to inverter (battery) mode.
|
|||||
|
ECO
|
No load detected in battery mode, automatically goes into hibernation mode,
|
||||||
|
Solar First
|
Preferential use of photovoltaic power generation, photovoltaic power generation is not enough, automatic switch into the power grid complementary, photovoltaic recovery automatic switch back to photovoltaic priority power supply.
|
||||||
|
Grid charging
|
0-30A
|
||||||
|
Protection
|
Overload, Short circuit, overvoltage, undervoltage, overtemperature, overcurrent, surge and so on
|
||||||
|
Panel indication
|
LCD+LED
|
||||||
|
Heat dissipation mode
|
Intelligent fan control
|
||||||
|
Communication
|
RS232/SNMP/WIFI(optional)
|
||||||
|
Environment
|
15°C~ + 50。 c 0-90% without condensation
|
||||||
[/vc_column_text][/vc_column][/vc_row]
